Power Source: 120 V AC
Amplification System: Class D
Power Consumption: 150 W (based on UL/CSA standards), 580 W (rated output 70 V line
Input
2 circuits
10 k?
XLR-3-31 type connector
CH 1 mode ON/OFF switch (ON: PARALLEL
Rated Output
2 channels: 250 W × 2 (70 V line
1 channel (BRIDGE): 500 W × 1 (140 V line
M4 screw terminal
Frequency Response: 20 – 20 (selectable with the inner jumper)
Total Harmonic Distortion:0.1% (1 kHz)
Protection Circuit
Protection against excessive current flow due to overload short circuit
temperature rise at power amp. heat sink (100? or more (212?F))
temperature rise inside the unit (80? or more (176?F))
S/N Ratio: 100 dB (A-weighted)
Crosstalk: 70 dB (A-weighted)
LED Indicator
Power (blue) × 1
Protect (red) × 2
Cooling: Forced air cooling
Operating Temperature: -10? to +40? (14?F to 104?F)
Operating Humidity: 90% RH or less (no condensation)
Finish Panel: Aluminum
