Key Features
- Laser 3LCD, 10,000 lumens, WUXGA
- Silent (35dB in normal mode) and light construction (22kg) is ideal for lecture theatres and seminar rooms
- 20 000 hours maintenance-free operation due to the dustproof construction and long-lasting eco filter
- Triple drive engine ensures non-stop operation with a failover function. A secondary backup signal input and the monitoring function reduce the impact of potential technical faults.
- Flexible installation with a choice of seven optional zoom lenses . Easy setup with Geo Pro software and DIGITAL LINK function
Product Specs
| Projector type | LCD projectors |
|---|---|
| Light source | Laser diodes |
| Light output*1 | 10,000 lm |
| Time until light output declines to 50 %*2 | 20,000 hours (NORMAL) |
| Resolution | 1920 x 1200 pixels |
| Contrast Ratio*1 | 3,000,000:1 (Full On/Full Off) * With [Dynamic Contrast] set to [3] |
| Center-to-corner zone ratio*1 | 85 % |
| LENS | Optional powered zoom lenses |
| Lens shift | Vertical (from center of screen) | ±60 % (±40 % with ET-EMW200, ±50 % with ET-EMW300) (powered) |
| Lens shift | Horizontal (from center of screen) | ±20 % (±19 % with ET-EMW200) (powered) |
| Keystone correction range | Vertical: ±40° (±14° with ET-EMW200/ET-EMW300, ±22° with ET-EMW400/ET-EMW500), Horizontal: ±15° (±8° with ET-EMW200/ET-EMW300) |
| Keystone correction range with optional ET-UK20 Upgrade Kit | Vertical: ±40° (±14° with ET-EMW200/ET-EMW300, ±22° with ET-EMW400/ET-EMW500), Horizontal: ±40° (±8° with ET-EMW200/ET-EMW300, ±15° with ET-EMW400/ET-EMW500)When [VERTICAL KEYSTONE] and [HORIZONTAL KEYSTONE] are used simultaneously, correction cannot be made exceeding a total of 55 °. |
| Installation | Ceiling/floor, front/rear, free 360-degree installation |
| Terminals | SDI IN | BNC x 1: 3G/HD-SDI input |
| Terminals | HDMI IN | HDMI 19-pin x 1 (Compatible with HDCP 2.2, Deep Color, 4K/60p signal input*3) |
| Terminals | DVI-D IN | DVI-D 24-pin x 1 (DVI 1.0 compliant, compatible with HDCP, compatible with single link only) |
| Terminal | RGB In | D-sub HD 15-pin (female) x 1 (RGB/YPBPR/YCBCR) |
| Terminals | SERIAL/MULTI PROJECTOR SYNC IN | D-sub 9-pin (female) x 1 for external control (RS-232C compliant) |
| Terminals | SERIAL/MULTI PROJECTOR SYNC OUT | D-sub 9-pin (male) x 1 for link control (RS-232C compliant) |
| Terminals | REMOTE 1 IN | D-sub 9-pin (female) × 1 for external control (parallel) |
| Terminals | REMOTE 2 IN | M3 x 1 for wired remote control |
| Terminals | Remote 2 Out | M3 x 1 for link control (for wired remote control) |
| Terminals | LAN | RJ-45 x 1 for network connection, 10Base-T, 100Base-TX (Compatible with PJLink™ [Class 2], Art-Net) |
| Terminals | DIGITAL LINK | RJ-45 x 1 for network and DIGITAL LINK connection (video/network/serial control) (HDBaseT™ compliant), 100Base-TX (Compatible with PJLink™ [Class 2], Art-Net, HDCP 2.2, Deep Color, 4K/60p signal input*3) |
| Terminals | DC OUT | USB Connector (Type A) x 1 (Output 5 V/2 A) |
| Power supply | AC 100-240 V, 50/60 Hz |
| Power consumption | 640 W |
| Cabinet materials | Molded plastic |
| Filter | Included (Estimated maintenance time: approx. 20,000 hours) |
| Operation noise*1 | 35 dB (NORMAL) / 30 dB (Quiet) |
| Dimensions (W x H x D) | 650 x 211*4 x 440 mm (25 19/32˝ x 8 5/16˝*4 x 17 21/64˝ ) (Without lens) |
| Weight*5 | Approx. 22.3 kg (49.2 lbs) |
| Operating environment | Operating temperature: 0–45 °C (32–113 °F)*6; Operating humidity: 10–80 % (no condensation) |
| Applicable software | Logo Transfer Software, Multi Monitoring & Control Software, Early Warning Software, Geometry Manager Pro (ET-UK20 Upgrade Kit, ET-CUK10 Auto Screen Adjustment Kit),Smart Projector Control for iOS/Android™ |
| Note | *1 Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2012 international standards. Value is average of all products when shipped. *2 Around this time, light output will have decreased by approximately 50 %. IEC62087: 2008 Broadcastcontents, NORMAL Mode, Dynamic Contrast [2], under conditions with 35 °C (95 °F), 700 m (2,297 ft) above sea level, and 0.15 mg/m3of particulate matter. Estimated time until light output declines to 50 % varies depending on environment. *3 4K signals are converted to theprojector's resolution (1920 x 1200 pixels) upon projection. Supported terminals: DIGITAL LINK/HDMI®. *4 With legs at shortest position. *5 Average value. May differ depending on the actual unit. *6 When using the projector at an altitude lower than 2,700 m (8,858 ft) above sea level,and the operating environment temperature becomes 35 °C (95 °F) or higher, the light output may be reduced to protect the projector. |
| Screen size [diagonal] | 2.03–12.7 m (80–500 in), 16:10 aspect ratio |
| Light output | 10,000 lm |
| LCD panel | Panel size | 25.4 mm (1.0 in) diagonal (16:10 aspect ratio) |
| LCD Panel | Number of pixels | 2,304,000 ( Pixels 1920 x 1200) pixels x 3 |
